Svodič DEHNguard DG PV 500 950500

Popis produktu:

SPD classification according to EN 61643-11 Type 2
SPD classification according to IEC 61643-1 Class II
PV voltage of earth-free PV systems (2 x DG PV ...) [UPV max] ? 1000 V
PV voltage of functionally earthed PV systems (thin film) [UPV
max]
? 500 V
Max. continuous operating d.c. voltage [UC] 500 V
Nominal discharge current (8/20 µs) [In] 20 kA
Max. discharge current (8/20 µs) [Imax] 30 kA
Voltage protection level for In [UP] ? 2 kV
Voltage protection level for 5 kA [UP] ? 1.7 kV
Response time [tA] ? 25 ns
Permanent short-circuit withstand capability [IK] 80 A d.c.
Reverse current withstand capability [Ipmax] 50 kA / 5 ms
Max. protection of main d.c. line at the inverter 315 A gR
Operating temperature range [TU] -40°C...+65°C
Operating state/fault indication green / red
Cross-sectional area (min.) 1.5 mm2 solid/flexible
Cross-sectional area (max.) 35 mm2 stranded/25 mm2 flexible
For mounting on 35 mm DIN rail acc
Enclosure material red thermoplastic, UL 94 V-0
Degree of protection IP 20
Dimension 2 mods., DIN 4
Ordering information
Type DG PV 500 SCP
Part No. 950 500
Packing unit 1pcs.
