Svodič DEHNrail M 255 FM 2P 953205

Popis produktu:

SPD according to EN 61643-11 Type 3
SPD according to IEC 61643-1/-11 Class III
Nominal a.c. voltage (UN) 230 V
Max. continuous operating a.c. voltage (UC) 255 V
Max. continuous operating d.c. voltage (UC) 255 V
Nominal load current a.c. (IL) 25 A
Nominal discharge current (8/20 µs) (In) 3 kA
Total discharge current (8/20 µs) [L+N-PE] (Itotal) 5 kA
Combined impulse (UOC) 6 kV
Combined impulse [L+N-PE] (UOC total) 10 kV
Voltage protection level [L-N] (UP) ? 1250 V
Voltage protection level [L/N-PE] (UP) ? 1500 V
Response time [L-N] (tA) ? 25 ns
Response time [L/N-PE] (tA) ? 100 ns
Max. mains-side overcurrent protection 25 A gL/gG or B 25 A
Short-circuit withstand capability for mains-side overcurrent
protection with 25 A gL/gG 6 kArms
Temporary overvoltage (TOV) [L-N] (UT) 335 V / 5 sec.
Temporary overvoltage (TOV) [L/N-PE] (UT) 400 V / 5 sec.
Temporary overvoltage (TOV) [L+N-PE] (UT) 1200 V + UCS / 200 ms
TOV characteristic [L-N] withstand
TOV characteristic [L/N-PE] withstand
TOV characteristic [L+N-PE] safe
Operating temperature range (TU) -40°C...+80°C
Operating state/fault indication green / red
Number of ports 1
Cross-sectional area (min.) 0.5 mm2 solid/flexible
Cross-sectional area (max.) 4 mm2 solid/2.5 mm2 flexible
For mounting on 35 mm DIN rails acc. to EN 60715
Enclosure material thermoplastic, red, UL 94 V-0
Place of installation indoor installation
Degree of protection IP 20
Capacity 1 module(s), DIN 43880
Approvals KEMA, VDE, UL, VdS, CSA
Type of remote signalling contact changeover contact
a.c. switching capacity 250 V/0.5 A
d.c. switching capacity 250 V/0.1 A; 125 V/0.2 A; 75 V/0.5 A
Cross-sectional area for remote signalling terminals max. 1.5 mm2 solid/flexible
Weight 102 g
Customs tariff number 85363010
GTIN 4013364108318
PU 1 pc(s)
