BALS 2838 (IPG 6353) IP 67

Přívodka vestavná 2838 (IPG 6353) IP 67, BALS

Popis:
Amperage: 63A
Poles: 5p (3p+N+PE)
Earth 'Clock' Position: 6 h
Voltage: 200/346 up to 240/415V
Frequency: 50 and 60Hz
Protection: IP67

Full Description:
Membership: screw terminal TE
Color code: red RAL 3000
Connection design: screw terminal as box terminal
Max. conductor: 16,0 mm2
fixing centres: flange 110x106 mm (HxW), fixing centres 90x90 mm

Material:
Housing material: Polyamide
Contact / Contact Carrier: contact carrier made of high temperature resistant material,
contacts and box terminals are brass nickel plated
