FINDER - 22.21.9.024.4000 - RELAY, DIN, SPNO, 24VDC
RELAY, DIN, SPNO, 24VDC
Relay Type: Modular
Coil Voltage VDC Nom: 24V
Contact Current Max: 30A
Contact Voltage AC Nom: 250V
Coil Resistance: 460ohm
Contact Configuration: SPNO
Coil Type: DC Monostable
Coil Current: 52.2mA
Nom Operating Power: 1.25W
Relay Mounting: DIN Rail
External Height: 84mm
External Width: 17.4mm
External Depth: 58.4mm
SVHC: No SVHC (19-Dec-2012)
Contact Current AC Max: 20A
Contact Material: AgSnO2
Contact Voltage AC Max: 250V
Current Rating: 20A
External Length / Height: 84mm
Mounting Type: DIN Rail
No. of Poles: 1
Series: 22
