Vazeb. člen 38.61.7.024.0050

Vazební člen 38.61.7.024.0050 1P/6A, 24V DC, BS, LED+EMC

Dimensions 93,6x6,2x76mm
Type interface module
Contact Form SPDT
Max. Switching Current 6 A
Coil Voltage 24VDC
Coil Resistance 0 Ohm
Coil Power 0 mW
Max. Switching Power 1500VA
Max. Switching Voltage 400VAC
Dielectric Strength (between c 6000V
Operate/Release time 5ms/6ms
Contact material AgNi
