Pozicionér BTL6-A110-M0600-A1-S115

Pozicionér BTL6-A110-M0600-A1-S115, Balluff

Popis:
Output signal: 0…10 V and 10…0 V
Connection: Connector, M12
Operating voltage: 20...28 V DC

Electrical data:
Ripple: 0.5 Vpp
Current consumption (at 24 V DC): ? 70 mA
Inrush current: ? 3 A / 0.5 ms
Overvoltage protected: Yes
Voltage-proof (GND – housing): 500 V DC
Ripple Ua max.: 5
Galvanic isolation: No
For dynamic loop applications: No
Error signal Ua rising: ? 10.2 V
Error signal Ua falling: ? 10.2 V
